Damper Rotation Torque Metal Disk Rotary Damper in Theater Seat,

Basic Info

Model NO.	TRD-47A-103
Warranty	at Least 50000 Cycles Without Oil Leakage
Certification	RoHS Complaints
Quality Test	100% Test
Life Cycle Test	Above 50, 000 Times
Special Request	OEM Design
Oil Type	High Quality Silicone Oil
Working Temperature	-10~50 Centigrate Degree
Direction of Damper	Both Direction
Base Diameter	47mm
Angle of Direction	360 Degree
Transport Package	CTN Package
Specification	47mm diameter
Trademark	Toyou
HS Code	8483900090
Production Capacity	500000PCS/Month

Product Description

HyDraulic Damper Rotary Shock Aborber,Metal Disk Rotary Damper For Spectator Seating, Lecture Room Seating

Detailed Photos

Product Description

This is two way disk rotary damper.
1. 360-degree rotation2. Damping in two direcitons(left and right ) 3. Base Diameter 47 mm,height 10.3mm 4. Torque range : 1N.m5. Material : Main body - Iron alloy 6. Oil Type: Silicone oil7. Life cycle - at least 50000 cycles without oil leakage

Product Parameters

Model		Max.torque	Direction
TRD-47A-103		1.0±0.3N·m	Both direction
(Note) Rated torque is measured at a rotation speed of 20rpm at 23°C±3°C

Product Drawing

Our Advantages

1.Advanced production management2.Stable and mature production lines3.Professional R&D team4.We have ISO9001, TS 16949 ,ISO 1400015.From purchasing of raw materials, parts production, assembly, engineering, testing, factory shipments are in strict accordance with top standard of production technology and quality supervision6.High quality for raw material : 100% inspect and test for the raw material.Most material imported from Japan.7.Stable quality of each batch product.8.Damper lifetime: more than 50000cycles.9.Strict Quality Restriction for dampers- 100% inspection and test in production.10.Quality inspection record is traceable at least 5 years.11.Superior performance of our dampers

Applications

Rotary damper are perfect soft closing motion control components used in many different industries such as toilet seat cover ,furniture,electrical household appliance,daily appliances,automobile, train and aircraft interior and exit or import of auto vending machines,etc.



Company Profile

Shanghai Toyou Industry is a leading manufacturer of rotary damper and have 20 years manufacture experience. We have our own mold workshop, injection workshop, production workshop and test equipment. We have a skilled and experienced technology team.All production process from purchasing of raw materials, parts production, assembly, engineering, testing, factory shipments are in strict accordance with top standard of production technology and quality supervision. We have ISO9001 quality and ISO14001 environmental management system certification and all raw materials are in line with ROSH standards, product 100% inspection and test in the production process and before storage, our company have a variety of testing equipment.Our dampers are mainly used in household appliances, sanitary equipment, furniture, car interior, industrial equipment, office equipment.Major customers including LG, Samsung, Siemens, Whirlpool, Midea, Haier, Rongshida, SANYO, Meiling, Kohler, HCG, TOTO, Galanz, Oranz ect.We make damper for many customers all over the world with high quality and good price.We OEM,ODM dampers for customers. welcome to cooperate with us.



FAQ

1.Where does rotary damper use?Rotary dampers are applied to a wide range of products, such as cabinets, vehicles, toilet seats, bins, coffee machines, gas stations, lawnmowers and any device with a lid or hinge that needs to open and close frequently, quietly, and smoothly.There are also many applications in the automotive sector: handles, fuel doors, glasses holders, cup holders and many others.Besides, rotary damper used in home appliance, machines and any place need safe and silent open and close.If you don't know how to use the damper, please ask us, we have professional engineer can help you to choose and guide you how to use it. 2.How to calculate torque.When using a damper on a lid,such as the one shown in the diagram,use the following selection calculation to determine the damper torque.Example) Lid mass M: 1.5 kg Lid dimensions L: 0.4m Load torque: T=1.5X0.4X9.8÷2 =2.94N·m Based on the above calculation,TRD -N1-*303 is selected.

3. If you I don't know how to use it, can you help me?Yes, you can give us your application,or what function do you want. We can recommend current damper or design and make new damper for you.

4. Damper warranty Our warranty is 500000 lifetime cycles. 5. Production timeLead time is 2-4 weeks.

6. Certicate and qualityOur company have ISO9001, 14001,TS16949 certificate. All product comply with CE and ROHS.We have tens of patent on the dampers.Welcome to contact us. Better product, better choice!
